Width excluding hanging bracket: 130 mm (5.1 in.)
Width including hanging bracket: 175 mm (6.9 in.)
Height excluding hanging bracket: 134 mm (5.3 in.)
Height including hanging bracket: 242 mm (9.5 in.)
Horizontal fixture spacing: 150 mm (5.9 in.) (center-to-center using interlock couplers)
Vertical fixture spacing: 150 mm (5.9 in.) (center-to-center using interlock couplers)
Depth: 146 mm (5.7 in.)
Weight including hanging bracket: 2.2 kg (4.85 lbs.)
Weight excluding hanging bracket: 2.0 kg (4.41 lbs.)

Beam Dimmer/Shutter: 0 – 100% continuous dimming, variable flash rate and duration, and atomic effects
Beam Dimming options: Choice of four dimming curves
Beam P3 Mix: Videomapping of fixture with variable crossfade between DMX control and video control
Aura Dimmer/Shutter: 0 – 100% continuous dimming, regular and random strobe effects
Aura Dimming options: Choice of four dimming curves
Aura Color mixing: RGB, independently variable 0 - 100%
Aura Color temperature control: Variable 2000 - 11,000 K
Aura Virtual Color wheel: 36 color presets, continuous rotation & random color
Aura PixelMapping: individual RGB control of each Aura pixel
Aura P3 Mix: Videomapping of fixture with variable crossfade between DMX control and video control
Built-in FX: Various pre-programmed FX on Beam, Aura and combination of both

Lens Diameter: 95 mm
Front Accessory Holder: PAR30 size

Beam/Strobe LED
LED Type: Warm White
Max. total lumen output: 2850 lumens (boost/strobe mode)
Max. total lumen output: 1400 lumens (continuous mode)
Beam Angle: 11 Degrees (half peak)
Field Angle: 22 Degrees (one-tenth peak)
Binning: Tight color and flux binning
Color Temperature: 2700 K
CRI (Color Rendering Index): >84
Resolution: 16-bit
Minimum LED lifetime: 50,000 hours (to >70% luminous output)

Aura Backlight LEDs
LED Type: RGB
LED Quantity: 16
Binning: Tight color and flux binning
Color Temperature: Variable (2000-11,000 K)
Resolution: 16-bit per color per pixel
Minimum LED lifetime: 50,000 hours (to >70% luminous output)

* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

AC Power, DMX and Network input: cable tail with PDE hybrid connector (IP65)
AC Power, DMX and Network thru: chassis-mount PDE hybrid connector (IP65)
All connections hot plugging compatible

AC power: 100-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 230 V, 50 Hz: 1.1 A
Typical earth-leakage current: 0.25 mA
Power Factor: 0.99 @ 100 V , 0.98 @ 120 V , 0.95 @ 208 V , 0.96 @ 230 V , 0.94 @ 240 V
Max current draw: 0.6 A @ 100 V / 120 V , 0.3 A @ 208 V / 230 V / 240 V
Typical current draw: 0.5 A @ 100 V , 0.4 A @ 120 V , 0.2 A @ 208 V , 0.2 A @ 230 V , 0.2 A @ 240 V *
Power Consumption
Maximum: 55 W
Typical: 50 W *
Idle: 4 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white.
Idle: no output.

LWR = Lumen-to-Weight Ratio

Junction Boxes
Passive Junction Box Power-DMX-Ethernet to PDE: P/N 91610001
Active Junction Box Power-DMX-Ethernet to PDE: P/N MAR-91700002

Adapters Cables
BreakIn Cable Power-DMX-Ethernet to PDE: P/N MAR-91700000
BreakOut Cable PDE to Power-DMX-Ethernet: P/N MAR-91700001
BreakInOut Cable Power-DMX to PDE: P/N MAR-91700003

Optical Accessories
VDO Atomic Dot Diffuser 60 Degrees: P/N 91610002
VDO Atomic Dot Diffuser 30 Degrees: P/N 91610005

Mechanical Accessories
Super Lightweight Half Coupler Rigging Clamp, black: P/N 91602018
G-clamp (vertical hanging installation only): P/N 91602003
Half-coupler clamp: P/N 91602005
Quick trigger clamp (vertical hanging installation only): P/N 91602007
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
Set of 10 VDO Atomic Couplers: P/N 91610003
VDO Atomic Half Coupler: P/N 91610004
VDO Atomic Interlock Adapter: P/N 91610006
VDO Atomic Pivot Coupler: P/N 91610007
VDO Atomic Dot Double Width Bracket: P/N 91616117
VDO Atomic Spigot Adapter 28mm: P/N MAR-91616118

Pre-Assembled Hybrid PDE Cables
Power+Data Cable Rental PDE-PDE 1m: P/N 91616001
Power+Data Cable Rental PDE-PDE 2,5m: P/N 91616002
Power+Data Cable Rental PDE-PDE 5m: P/N 91616003
Power+Data Cable Rental PDE-PDE 10m: P/N 91616004
Power+Data Cable Rental PDE-PDE 25m: P/N 91616005

Bulk Hybrid PDE Cable and Connectors
Power+Data Connector PDE Male: P/N 91611701
Power+Data Connector PDE Female: P/N 91611702
Power+Data Cable Power-DMX-Ethernet Rental 100m: P/N 91616006

DemoKit
VDO Atomic Dot Demo Kit: P/N 91311001

Flightcase
Flightcase for 15 x VDO Atomic Dot: P/N 91515053
Flightcase Extender for 15 x VDO Atomic Dot: P/N 91515054
